Features

Studio quality transducers
For accuracy, and rich bass response: 80 Hz - 20 Khz

Exceptional output
35 watt per-channel po wer amplifier and high sensitivity drivers produce exceptional output: 111 dB peak SPL

Balanced XLR, ¼”, and unbalanced RCA inputs
Allow connection to a range of signal sources

Stereo headphone jack
Allows monitoring using headphones

High frequency adjust control
Allows the user to contour HF response to application requirements

Magnetically-shielded transducer
For use near CRT monitors and magnetically sensitive equipment

Internal peak limiter and overload protection circuit
Protects the system from damage caused by continuous over-driving

Wall-mount capable
Using optional MTC-2P mounting kit

Included snap-on pedestal
Optimize listening angle for desktop applications
Specs & Downloads
Item# C2PM
Description
Rich, accurate performance
The Control 2P Compact Powered Reference Monitor System combines JBL’s legendary loudspeaker design with powerful amplification to deliver rich, accurate performance for the most demanding audio applications. The compact design, rugged enclosure, and professional feature-set make the Control 2P Compact Powered Reference Monitor ideal for desk-top recording and video production, audio visual presentations, professional broadcast applications, and monitoring of electronic musical instruments.
General Specifications
- Transducers
- LF - 135 mm (5.25 in) low frequency loudspeaker ; HF - 19 mm (.75 in) Polycarbonate dome tweeter
- Frequency Range
- 80 Hz - 20 kHz
- Amplifier Power
- 35 Watts
- Maximum SPL
- 111 dB
- Crossover Frequency
- 4.2 kHz
- Input Sensitivity
- +4 dBu XLR 1/4"; 0 dBu RCA
- Signal Input Connectors (x2)
- Balanced Neutrik® Combo XLR 1/4" TRS ; Unbalanced RCA
- Power Requirements
- 19 VDC / 3.42 A - use only supplied power supply
- Headphone Jack
- 3.5 mm (1/8")
Dimensions
- Height
- 9.3 in (235 mm)
- Width
- 6.3 in (159 mm)
- Depth
- 5.6 in (143 mm)
- Net Weight
- 5.5 lbs (2.6 kg)
What's in The Box?
- 1 x Control 2P Powered Host Speaker
- 1 x Universal Power Supply
- 1 x Snap-On Pedestal
- 1 x User's Guide
