JBL TS600-Z

TS 600 Refurbished

300-watt, 6-1/2” bookshelf speaker

Variations
$886.99886.99 each
$1,266.95 Save 30%
Product Actions
Add to cart options
Promotions

This item is currently not available.

Features

25 – 300 watts suggested amplifier range

25 – 300 watts suggested amplifier range

JBL engineers designed the JBL TS600 bookshelf speaker to deliver enhanced, room-filling sound from a compatible AVR (audio/video receiver) or 25- to 300-watt power amplifier.

Magnesium-alloy diaphragms

Magnesium-alloy diaphragms

The lightweight and stiff magnesium alloy in the TS600 speaker’s dome diaphragms provides for exceptional bass response with low distortion and minimizes unwanted vibrations. You’ll experience natural, realistic tones from all of your music and movies.

Dual 6-1/2" (165mm), inverted-dome woofers

Dual 6-1/2" (165mm), inverted-dome woofers

Small enough to maintain a low profile yet large enough to deliver powerful sound and great bass response, the TS600’s driver and the rubber of its surround create a seamless sound field and minimize distortion, even at high volumes.

4" (100mm), inverted-dome midrange driver

4" (100mm), inverted-dome midrange driver

The midrange frequencies, where vocals are reproduced, are the heart and soul of great audio. They’re also the area where departures from faithful reproduction are most noticeable. Since the TS600 midrange driver uses a magnesium alloy that reproduces vocals with incredible accuracy and low distortion, the voices that you hear from this speaker come out clear and true.

1" (25mm), magnesium-alloy tweeter

1" (25mm), magnesium-alloy tweeter

The TS600’s thin but rigid magnesium-alloy high-frequency dome driver delivers accurate, undistorted response up to 40kHz, well beyond the range of human hearing. The driver’s back cavity is shaped to ensure no external loss of sound.

Extremely smooth and wide frequency response

Extremely smooth and wide frequency response

With a frequency response of 35Hz – 40kHz, the TS600’s sound reproduction is extremely smooth and extended in every direction. The system’s directivity and power response are highly uniform, its harmonic distortion is reduced to inaudible levels, and its dynamic linearity is unparalleled.

Exquisite, furniture-like enclosure

Exquisite, furniture-like enclosure

Measuring 11-1/2 by 19-1/2 by 9-3/5 inches (292 by 495 by 245 millimeters), the TS600 takes up little space while providing massive sound. The speaker features SonoGlass® flares for the top plate, a bass-reflex port on the back and plenty of high-grade and low-loss air-core coils – and its cabinet helps to keep your audio sounding as if it were coming straight from a recording studio. Its gloss-black body, trimmed in a natural-wood, furniture-like finish, is a perfect complement to any home’s décor.

TS 600 - Cherry - Hero

Specs & Downloads

General Specifications

Series TS Series
Type Bookshelf Speakers
Finish Cherry

Audio Specifications

Frequency Response (-3dB) 44Hz - 38kHz
Crossover Frequencies 700Hz; 12dB/octave
Nominal Impedance 6 ohms
Maximum Recommended Amplifier Power 150W
Sensitivity (2.83V@1m) 85dB

Speaker Specifications

Low-Frequency Transducer 6-1/2" (165mm) Magnesium-alloy, shielded; with cast-aluminum frame
Midrange Transducer 4" (101mm) Magnesium-alloy, neodymium motor assemblies, shielded
High-Frequncy Transducer 1" (25mm) Magnesium-alloy, shielded

Dimensions

Height (mm) 495
Height (in) 19-1/2
Weight (kg) 12.2
Weight (lb) 27
Width (mm) 292
Depth (mm) 244
Width (in) 11-1/2
Depth (in) 9-5/8

Documents & Downloads

The latest owner's manuals, quick start guides, and documents.

Reviews and Q&A

Customer Reviews

Product Q&A

Support

Search Result For ""

Register your
JBL product

Do you own this product? Register it here in case you need to claim warranty

Register Now

Can’t find what
you’re looking for?

Are you looking for product support, documentation, how-tos or older products?

JBL Support

Powerful and compact 6-1/2" (165mm) bookshelf speaker.

For more than 60 years, JBL® engineers have provided innovative sound solutions in venues as large as concert arenas and sports stadiums, and as small as the cabins of automobiles – and everywhere in between. And one space where listeners embrace JBL technology is the home – a place where the compact JBL TS600 fits right in. This three-way bookshelf speaker delivers robust, precise sound with extraordinary fidelity. It features a 6-1/2-inch (165-millimeter) inverted dome woofer that provides resounding bass, a 4-inch (100-millimeter) driver for distinct vocals and a 1-inch (25-millimeter) tweeter for clear, sharp highs. This outstanding speaker produces frequencies as low as 35Hz and as high as 40kHz, well above the range of human hearing. It also features magnesium-alloy diaphragms, which enable low-distortion sound without the unwanted vibrations sometimes associated with powerful speakers. The TS600 is also stunning to see, with its gloss-black body trimmed in a furniture-like enclosure. We’ve designed the cabinet to ensure that there is no sound loss and that you hear your audio as if it’s coming straight from a recording studio. We’ve included floor stands so you can position your speaker next to your TV (or your ears). If it’s realistic, studio-quality sound that you seek, then look no further than the JBL TS600.
