- SOLD OUT



Features
165 mm (6½ in) low frequency driver
Provides solid, powerful bass response to 50 Hz
Pure titanium 25 mm (1 in) dome
Delivers high frequency response to 20 kHz
Magnetically shielded transducers
Allows for use in close proximity to video monitors
Protection circuitry
Prevents system damage
Bypass capacitors
For outstanding transient accuracy
Pleasing shape
Fits easily into any environment
Specs & Downloads
Item# CONTROL 5AM
Description
Unprecedented versatility
The Control 5 is a high performance, wide range control monitor suitable for use as the primary sound source in a variety of applications. Smooth, extended frequency response combines with wide dynamic capabilities to provide acoustic performance that makes the Control 5 ideal for recording studios, audio-video control rooms, remote trucks and broadcast studios. Clean, functional visual design makes the Control 5 also ideal for foreground music systems, moderate level sound reinforcement, discotheques and music playback systems. A 165 mm (6½ in) low frequency driver provides solid, powerful bass response to 50 Hz. High frequency response to 20 kHz is handled by a pure titanium 25 mm (1 in) dome. Both transducers are magnetically shielded, allowing for use in close proximity to video monitors. The dividing network incorporates protection circuitry to prevent system damage and utilizes high quality components including bypass capacitors for outstanding transient accuracy. Molded of dense polypropylene foam, with a finish of black or white, the Control 5 enclosure offers a pleasing shape that fits easily into any environment. Wall, ceiling, rack and tripod mounting systems allow positioning of the system in exactly the right spot for optimum performance.
General Specifications
- Frequency Range (± 3 dB)
- 75 Hz to 20 kHz
- Power Capacity
- I75 W
- Sensitivity
- 89 dB SPL, 1 W, 1 m (3.3 ft)
- Directivity Factor (Q)
- 2.8
- Directivity Index (DI)
- 4.5
- Nominal Impedance
- 4 ohms
- Crossover Frequency
- 3 kHz
- Polarity
- Positive Voltage to + terminal causes outward low frequency cone motion
- Enclosure Material
- Polypropylene structural foam
Dimensions
- Height
- 15.25 in (387 mm)
- Width
- 9.875 in (251 mm)
- Depth
- 9 in (229 mm)
- Net Weight
- 10 lbs (4.5 kg) each
- Shipping Weight
- 24 lbs (11 kg) pair
Documents & Downloads
Reviews and Q&A
Customer Reviews
Product Q&A
I may have accidentally over-driven a pair of these and no sound now comes out -- is there a replaceable fuse or a way to reset the protection circuit if it's tripped?
Where do I get speaker stands for the Control 5?
Where is the WHITE version of the Control 5...?
can i use 5 pcs. JBL Control 5 as a 5.0 hometheater?
