JBL 306P MkII

Details
Variations

Powered 6" Two-Way Studio Monitor

$149.00149.0 each $199.00 Save 25%
Promotions
Free Ground Shipping
Product Actions
Add to cart options

In stock and ready to ship

Order within 20 hrs 37 mins with Free Ground Shipping and receive by Thu, Dec 12
Your zip code 20149 edit | Want it faster?
Patented Image Control Waveguide

Patented Image Control Waveguide

For detailed imaging and a broad, room-friendly sweet spot

Next-generation JBL transducers

Next-generation JBL transducers

For optimized transient response and improved linearity

New Boundary EQ settings

New Boundary EQ settings

Compensate for low frequency variants introduced by the environment

3-position HF Trim switch

3-position HF Trim switch

Adjusts high-frequency output to room acoustics or personal preferences

Patented Slip Stream™ low-frequency port

Patented Slip Stream™ low-frequency port

For superior bass performance at all playback levels

Dual integrated, custom Class-D amplifiers

Dual integrated, custom Class-D amplifiers

Provide 112 watts of power for high output and dynamic range

Flexible connectivity

Flexible connectivity

With balanced XLR and 1/4" TRS inputs, +4dBu / -10dBV input-sensitivity switch and adjustable volume control

Engineered to JBL Linear Spatial Reference design criteria

Engineered to JBL Linear Spatial Reference design criteria

For outstanding accuracy in any working space

Strenuous JBL 100-hour full-power test

Strenuous JBL 100-hour full-power test

Ensures years of reliability

Sleek, modern design

Sleek, modern design

Provides a visual upgrade to any studio

Powered 6" Two-Way Studio Monitor

The next-generation JBL 306P MkII powered studio monitor makes legendary JBL performance available to every studio. With the revolutionary JBL Image Control Waveguide and refined transducers, JBL 306P MkII offers stunning detail, precise imaging, a wide sweet spot and impressive dynamic range that enhances the critical listening capabilities of any modern workspace. Featuring patented technologies derived from the JBL 7 Series and M2 Master Reference Monitors and sporting a sleek, modern design, JBL 306P MkII delivers outstanding performance and an enjoyable mix experience at an accessible price.

Item# 306PMKII

General Specifications

LF Driver Size 165 mm (6.5")
HF Driver Size 25 mm (1")
HF Driver Type Soft dome
Crossover 1425Hz 4th order acoustic Linkwitz-Riley
Power Configuration Bi-amplified
HF Driver Power Amp 56 W Class D
LF Driver Power Amp 56 W Class D
Frequency Response 47Hz – 20kHz (±3dB)
Frequency Range 39Hz – 24kHz (-10dB)
Low Frequency Extension 39Hz (-10dB)
Maximum Continuous SPL 92dB
Maximum Peak SPL 110dB
Maximum Peak Input Level +6dBV / +20.3dBu (-10dBV / +4dBu)
System Distortion Criteria <10% THD at maximum output with full compressor / limiter engagement
Electrical Distortion Criteria 0.2% THD @ 1kHz / 2.83VRMS output; <1% THD @ 1kHz, full rated output
Signal to Noise Ratio 75dBA (A-Weighted), 70dBr (unweighted), relative to 2.83VRMS output
Coverage Pattern 120° x 90° (horizontal x vertical)
HF Trim Control -2dB, 0dB, +2dB
Boundary EQ LF Shelf @ 50Hz
AC Input Voltage 100 – 240VAC (±10%), 50 / 60Hz

Dimensions

Height 361 mm (14.2")
Width 224 mm (8.8")
Depth 282 mm (11.1")
Net Weight 6.1 kg (13.42 lbs)

Design

Enclosure Type Ported
Enclosure Construction 15mm MDF
Enclosure Finish Matte black PVC
Baffle Construction Injection-molded structural ABS

Audio Input

Analog Input Types 1 x XLR female, 1 x TRS female, balanced
Input Sensitivity 92dB / 1m (-10dBV Input)
  • 1 x 306P MkII studio monitor
  • 1 x Power cord
  • 1 x Quick setup guide
  • 4 x Peel-off rubber pads
product box

Manuals & Downloads

The latest owner's manuals, quick start guides, and documents.

Declaration of Conformity

548 KB

Quick Start Guide (EN)

2 MB

Owner's Manual (EN)

2 MB

Data Sheets (EN)

223 KB

Search Result For ""

5 Years

Pro Products purchased online or from an authorized local retailer and under warranty may qualify for an exchange with a valid receipt.

pro Purchases made from an unauthorized dealer will not be eligible for exchange.
