Built-in Wi-Fi
For wireless control of your system from anywhere in the venue

Free PRX Connect mobile app for iOS and Android
Provides wireless control over volume levels, 8-band parametric EQ and up to 50ms of speaker delay to fine-tune your sound

Class-leading 1500-watt amplifier
Delivers ample power to fill your venue
Features

JBL Differential Drive® transducers
For higher SPL in a lightweight design

Crown-designed input panel
With XLR, 1/4”, and RCA inputs, plus XLR loop-through

Durable construction
Wooden cabinets, tour-proven DuraFlex™ finish, and dent-resistant cloth-backed 16-gauge grilles

Universal power supply
For worldwide compatibility

Demanding 100-hour test regimen
Ensures reliable performance

Intelligent variable-speed fan
Activates only when needed to reduce noise

Scalable system
Integrates with other JBL portable powered PA's
Frequently Bought Together
Specs & Downloads
Item# PRX812W
Description
Loudest-in-class Sound Reinforcement System with easy Wi-Fi Control
The JBL PRX812 is a full-range speaker designed for main system and floor monitor applications. Featuring a 12”, two-way, bass-reflex design powered by a 1500-watt class-D amplifier, PRX812 delivers incredible volume in a lightweight and compact form factor. It has been designed to deliver maximum performance for its weight and size as both a stage monitor and a front of house main PA. Two user selectable EQ settings are provided to optimize the system for either application. With a dual socket pole mount the PRX812 is a perfect match with a PRX818XLF subwoofer, offering a high performance self-powered sub/sat system. The PRX800 series integrates embedded ioSYS technology which enables easier setup and control when used with the HARMAN Connected PA app and compatible products. Connected PA delivers seamless plug-and-play operation with a variety of HARMAN equipment and enables you to control your entire live sound system with one app. Products within the Connected PA system self-identify and retain presets for effortless setup, and setup wizards help you quickly optimize speaker levels, configuration settings and EQ. Current products with embedded ioSYS technology and HARMAN Connected PA compatibility include the Ui24R mixer, JBL PRX800 loudspeakers, dbx Di1 direct boxes, and AKG P5i microphones and the MDAi dynamic microphone adapter.
General Specifications
- Power Rating (W, Continuous)
- 750
- Power Rating (W, Peak)
- 1500
- Frequency Response Hz (±3 dB)
- 56 - 20,000
- Maximum SPL (peak dB)
- 135
- Coverage Pattern (Nominal)
- 90° x 50°
Dimensions
- Height (in)
- 23.6
- Depth (in)
- 13.4
- Width (in)
- 15.1
- Weight (lbs)
- 40.0
- Height (mm)
- 599.0
- Width (mm)
- 385.0
- Depth (mm)
- 341.0
- Weight (kg)
- 18.1
Design
- Finish
- Obsidian DuraFlex™ finish
Features
- Dual-angle pole-mount socket
- Yes
- M10 suspension points
- Yes
- Built-in Wi-Fi
- Yes
- Mobile app available for iOS and Android
- Yes
- Transducer Differential Drive JBL
- Yes
Documents & Downloads
Reviews and Q&A
Customer Reviews
Product Q&A
Can you hook this up to a reciever to watch in theatre i.e. blu ray, my reciever has rca Jack's but only one for left and right, this has two, pls advise.
Is this speaker Bluetooth
what is the difference in prx and srx
1. What is the input power requirements in Amps at 120VAC for the PRX812W, PRX815W and PRX818XLFW PA speakers? 2. Do you have any diagrams for Flying the PRX812W? Can it be hung in a horizontal orientation?
(1) I can't find the PRX Connect app on Google Play. Where can this be downloaded from? (2) Does the claimed PRX Connect app allow mixing level control of the two input channels for the PRX812?
Does it bluetooth
I have a PRX800 series. It appears to have some amber lights that are on inside the back of the speaker. One blinking and one that is steadily on. What does this means and how to fix it?
Can you connect your phone using the red and white audio port
