JBL Marine MA4505
- Compact size
- High- and low-level inputs
- Selectable Output and Variable Adjustment Crossovers
- Product Value
- Cosmetic Appeal
- Conformal-Coated PCB
- Variable Crossovers
- Big Dynamic Power
$529.95
Please click PERSONALIZE to get started or select a design
Apple Pay™ Users: By continuing to checkout you understand and agree to our Terms of Sale, Terms of Use and Privacy Policy.
Your zip code edit
In stock and ready to ship
Features
Compact size
JBL Marine amplifiers feature a slim chassis and a small footprint to allow for installation in tight spaces
High- and low-level inputs
Speaker-level and low-level inputs let JBL Marine amps integrate with just about any audio input.
Selectable Output and Variable Adjustment Crossovers
JBL Marine amps feature selectable all-, high-, or low-pass crossovers with variable electronic frequency adjustment to allow for fine-tuning multiple system configurations.
Product Value
JBL power and performance at an affordable price point
Cosmetic Appeal
Product family look and feel to meet the needs of our JBL customers
Conformal-Coated PCB
JBL Marine amplifiers are engineered to withstand harsh marine conditions, with fully “marinized” circuit boards to ensure flawless power delivery, year after year
Variable Crossovers
Onboard 12dB electronic crossovers, with selectable full-range, high-pass & low-pass switching, provide tuning options for systems of any size
Big Dynamic Power
Output power is perfectly matched to meet the needs for your JBL marine products
Specs & Downloads
Item# MA4505
Description
Weather-resistant & high-performance marine amplifiers
New weather-resistant & high-performance JBL Marine amplifiers deliver impressive power from a compact chassis designed to withstand outdoor environments. Available with 4-channel and 5-channel outputs. JBL Marine amplifiers incorporate our latest amplifier topology that includes selectable all-, high-, or low-pass crossovers with variable electronic frequency adjustment for precision system tuning. Engineered for harsh marine conditions, with power and performance to meet the needs of any outdoor audio system, JBL Marine amplifiers are the perfect match for all of your JBL marine products.
General Specifications
- Max Power
- 1800W Peak
- RMS Power Output @ 2Ω (subwoofer)
- 500W x 1, <1% THD+N
- RMS Power Output @ 4Ω (subwoofer)
- 320W x 1, <1% THD+N
- RMS Power Output @ 2Ω (full-range)
- 65W x 4, <1% THD+N
- RMS Power Output @ 4Ω (full-range)
- 45W x 4, <1% THD+N
- RMS Power Output @ 4Ω Bridged (full-range)
- 130W x 2, <1% THD+N
- Signal-to-Noise Ratio (sub)
- >80dB (ref 1W output @ 4Ω)
- Signal-to-Noise Ratio (full-range)
- >80dB (ref 1W output @ 4Ω)
Documents & Downloads
Reviews and Q&A
Customer Reviews
Rated 5 out of
5
by
WesScott from
Nice size, and well built
Ran this for an entire day at the lake and it never got hot. Good product so far.
Date published: 2019-04-22
Product Q&A
My Kenwood head unit remote wire controls this amp opposite. When I turn on the head unit the amp turns off and the power light flashes every 4 seconds. When I turn the head unit off the amp turns on. No protect light issues. My second amp works Fine
Please try to isolate the issue by connecting a +12V line to the Remote terminal of your MA4505. If the amp won't turn on, then there's an internal problem within the unit. Please reach out to our Customer Support for further assistance.
Date published: 2022-07-12
Does this unit require a head unit or can it be controlled via Bluetooth?
Our JBL Marine MA4505 is a Multi-element high-performance, 5-channel amplifier and it does require a head unit for the amplifier to work. This amplifier does not have a Bluetooth function.
Date published: 2022-02-28
