Features

4” PolyPlas driver delivers unrivaled purity and power
We have years of JBL acoustic testing under our belt to back our sound up. With its 4” PolyPlas driver delivering unrivaled midrange accuracy and power, we’ll let a masterpiece speak for itself.

1” CMMD® Lite high-frequency driver and High Definition Imaging (HDI) waveguide bring cinema-grade sound to your listening experience
The consummation of 67 years of pioneering sound research at our JBL labs, the Studio 220 incorporates bold technologies like a High Definition Imaging (HDI) waveguide and a 1” CMMD Lite high-frequency driver into its design. Together, these advances let you experience your sound cinematically – in all its precision imaging, high-frequency detail, natural balance, and full spectrum mastery.

Visually striking 21st century design features that can’t fail to seduce
The JBL way is to make it look as good as it sounds. And with the Studio 220, we’ve made no exception. With 21st century elegance that incorporates soft-rounded edges, black gloss paneling, and soft-touch paint, we’ve built something that seduces the eye as much as it commands the ear.
Specs & Downloads
Item# STUDIO220BKAM
Description
Sonic dynastyfused with high-tech destiny
You’ll never look at your bookshelves the same. … or wherever else you decide to place these uncannily adept JBL® loudspeakers. As part of the new 10-piece JBL Studio 2 loudspeaker series, the Studio 220 bookshelf speaker was built to speak the languages of both legacy sound and forward-thinking technology. Tested relentlessly in the world’s most advanced sound research lab – our own – as well as pitted against competitors in real world comparative listening studies, we’ve engineered this loudspeaker to go above and beyond. We incorporated a front-firing 4” PolyPlas midrange speaker and a rear-firing Slipstream bass port that envelop listeners in tight, accurate bass. We always could have stopped there – but that’s not the JBL way. We took other design cues from our work building the world’s most legendary recording studios, giving our Studio 220 the kind of performance sound normally found at cinemas and multiplexes: a 1” CMMD® Lite high-frequency driver that ensures low-distortion, and a High Definition Imaging (HDI) waveguide design that offers pinpoint sound imaging and studio-grade balance. Then we topped it off with seductive features like gloss black paneling, soft rounded edges, and your choice of either Black or Espresso wood-grain finish. We ran wild with sound and vision, combining the power and precision of high-tech audio with the sleek urbanity of “it-factor” design. For those able to hear the truth, we’re confident you’ll hear it full volume – at first listen.
General Specifications
- Finish
- Black
- Type
- 2-way 4” Bookshelf Loudspeakers
Audio Specifications
- Sensitivity
- 86 dB
- Nominal Impedance
- 8 Ohms
- Maximum Recommended Amplifier Power
- 20 – 125W
- Frequency Response
- 60 Hz – 22 kHz
Speaker Specifications
- High-Frequency Transducer
- 25mm (1") CMMD®Lite high frequency dome
- Low-Frequency Transducer
- 100mm (4") PolyPlas low-frequency transducer
Dimensions
- Width ( in)
- 6-5/8
- Depth (in)
- 7-3/32
- Height (mm)
- 260
- Height (in)
- 10-1/4
- Weight (kg)
- 3.7
- Depth (mm)
- 180
- Weight (lb)
- 8.1
- Width (mm)
- 168
Control and Connection Specifications
- Connector Type
- Gold-plated binding-post speaker terminals
