Features
High power handling, wide frequency response and low distortion
Make the Control 26CT ideal for sound systems requiring a higher fidelity sound from ceiling loudspeakers
Broad 110° coverage pattern
Allows for fewer speakers to be used, making for a simpler and less expensive installation
All-in-one speaker assembly
JBL ceiling speakers are packaged as complete assemblies, including integral backcan, front grille, above-ceiling backing and tile bridge support hardware.
Includes a multitap transformer
For use on 70V or 100V line distribution systems
Specs & Downloads
Item# CONTROL 26CT
Description
6.5" Ceiling Loudspeaker Transducer Assembly w/Multitap Transformer
The Control 26C is a compact ceiling speaker providing premium performance in background, foreground music sound systems. The Control 26C is perfectly suited for a wide variety of applications from casinos and hotels to upscale restaurants and themed locations. High power handling, wide frequency response and low distortion make the Control 26C ideal for sound systems requiring a higher fidelity sound from ceiling loudspeakers. The premium performance capability ensures excellent sound character, providing pleasant, enveloping sound throughout the listening area. The Control 26C’s 16 ohm impedance allows use of multiple speakers in parallel without having to use a more expensive constant voltage distributed system. The optional Control 26CT version includes a multitap transformer for 70V/100V systems. JBL’s exclusive SonicGuard overload protection is a non-invasive loudspeaker protection system that is inaudible to the listener, ensuring reliability while providing full fidelity sound. The computer-optimized ported enclosure delivers warm, smooth bass response. Low frequency output can be further augmented with the addition of one of the Control Contractor subwoofer models. The 165 mm (6.5 in) woofer features a polyurethane-coated cone and pure butylrubber surround for long life, even in high humidity environments. An aluminum voice coil former provides extra cooling for greater long-term power handling. The coaxially mounted 19 mm (¾ in) titanium coated tweeter provides crisp, clear highs. Diffraction-loading of the tweeter provides wide, even coverage of the listening area. The extremely broad 110° coverage pattern allows for fewer speakers to be used, making for a simpler and less expensive installation.
General Specifications
- Frequency Range (-10 dB)
- 75 Hz - 20 kHz
- Power Capacity
- 150 Watts Continuous Program Power ; 75 Watts Continuous Pink Noise
- Nominal Sensitivity
- 89 dB SPL, 1W @ 1 m (3.3 ft)
- Nominal Coverage Angle
- 110° conical coverage
- Directivity Factor (Q)
- 5.9 averaged 500 Hz to 4 kHz
- Directivity Index (DI)
- 4.6 averaged 500 Hz to 4 kHz
- Rated Maximum SPL
- 107 dB @ 1 m (3.3 ft)
- Transformer Taps
- 070V = 60W, 30W, 15W & 7.5W taps ; 100V = 60W, 30W, & 15W taps
- Low Frequency Transducer
- 165 mm (6.5 in) Polypropelene-coated, 1" coil on aluminum former
- High Frequency Transducer
- 19 mm (0.75 in) Titanium coated polyester
- Safety Agency Rating
- Suitable for use in air handling spaces per UL1480, UL2043, NFPA90 & NFPA 70. S7232/UL Listed, Signaling Speaker. Transformer UL registered per UL1876. In accordance with IEC60849/EN60849
- Included Accessories
- C-shaped support backing plate ; 2 tile support rails (fits both 2 x 4 ft or 600 x 1200 mm tiles) ; Cutout template ; Paint shield ; Removable locking wiring connector
Dimensions
- Outside Dimensions (H x Dia)
- 210 x 252 mm (8.3 x 9.9 in) ; 190 mm (7.5 in) front of ceiling tile to back of backcan
- Cutout Size
- 220 mm (8.75 in)
- Net Weight (ea)
- 4.2 kg (10 lb)
- Shipping Weight (pair)
- 9.7 kg (21 lb)
Design
- Backcan
- Formed steel
- Baffle/Rim
- Medium impact polystyrene, fire rated UL94V-0
- Termination
- Removable locking connector with screw-down terminals. 2 input terminals and 2 loop-thru output terminals. Max. wire 12 AWG (2.5 mm)
What's in The Box?
- 1 x Control 26CT
- 1 x C-shaped support backing plate
- 2 x Tile support rails (fits both 2 x 4 ft or 600 x 1200 mm tiles)
- 1 x Cutout template
- 1 x Paint shield
- 1 x Removable locking wire connector
