Club 625SQ

Carbon Fiber Woofer with Plus One™ Architecture for Ultimate Sound Quality

Patented (US patent #7,548,631) Plus One™ cones provide more overall speaker-cone area than other speakers for the same size, which bring the louder bass. While the high-end carbon fiber woofer material provide the accuracy and clear musical character.

Edge-driven Silk Dome Tweeter

Club SQ speakers have edge-driven silk dome tweeter, which delivers a broader and smoother high frequency response, never-harsh regardless of output level than more commonly used w-domes.

Adjustable Tweeter Output Level

The Club SQ Speakers offer a tweeter output level control of 0dB or +3dB to optimize system linearity based on installation location.

Features

Club 625SQ Incredibly Y40 Ferrite Magnet  for higher sensitivity - Image

Incredibly Y40 Ferrite Magnet for higher sensitivity

The Club SQ Speakers use the Y40 Ferrite Magnet, which can bring higher sensitivity compared with the commonly Y30 Ferrite magnet.

Club 625SQ I-Mount Tweeter Mounting Kit - Image

I-Mount Tweeter Mounting Kit

The I-Mount™ (patent no. 5,859,917) tweeter-mounting system allows easy and versatile installation of tweeters in each of the component systems. It includes a flush cup and surface-mount mounting hardware. With a 1-3/4” cutout and a 1" mounting depth, installation becomes a snap. This allows the tweeter to be flush-mounted and can be angled up to ±40 degrees. Locknuts are included to keep everything in place, and the tweeter can be replaced without removing the whole assembly.

Specs & Downloads

Item# JBLSPKCB625SQAM

Description

Pro Car Audio by JBL

Club coaxial and component speakers bring JBL pro sound to more vehicles. Their compact design means they’ll fit into more vehicles than many of our competitors, and their high sensitivity delivers outstanding performance even with modestly-powered factory systems. Carbon Fiber Woofer with Plus One™ architecture deliver hard-hitting bass and long performance life. Edge-driven silk dome tweeters deliver broader and smoother high frequency response, never-harsh regardless of output level. Starfish™ Tweeter Mounting Adapter and I-Mount Tweeter Mounting Kit in component speaker system for easy installation.

General Specifications

Power Handling
75W RMS, 225W peak
Sensitivity (@ 2.83V)
93dB
Frequency Response
48Hz – 21kHz
Nominal Impedance
3.0 ohms

What's in The Box?

  • 2 x Speakers
  • 2 x Grilles
  • 1 x Foam gasket
  • 16 x Screws
  • 8 x Speed clips
  • 2 x Plastic multi-hole adapter rings
