JBL Stage Amplifier A6002
$139.95
0.0 (0)
Write a review

Features

JBL Stage Amplifier A6002 Value Engineered - Image

Value Engineered

Stage amplification provides true JBL performance at an affordable price while now lacking the features needed to properly tune and optimize performance.

JBL Stage Amplifier A6002 Compact footprint - Image

Compact footprint

With it becoming more and more difficult to find spacious locations for amplifier mounting, Stage has been developed in a small compact form factor to allow more location versatility.

JBL Stage Amplifier A6002 Full On-Board Protection - Image

Full On-Board Protection

Stage amplification has on-board circuitry to protect them from shorts, temperature, overvoltage and undervoltage. An LED indicator is included on all four models to let you know when one of these condutions exists.

JBL Stage Amplifier A6002 Reliability - Image

Reliability

JBL is one of the greatest audio brands in the world. This is not a coincidence given the arduous testing and quality control. We take our craft seriously and want every consumer to have a world class experience that lasts and lasts.

JBL Stage Amplifier A6002 Input Level Control - Image

Input Level Control

When Low-level inputs are used, this control adjusts the input sensitivity between 200mVrms and 5.0Vrms. When High-level inputs are used, this control adjusts the input sensitivity between 0.5Vrms and 15Vrms.

JBL Stage Amplifier A6002 Switchable bass EQ - Image

Switchable bass EQ

This provides an avaiable bass boost at 45Hz of 6dB or 12dB, serving as a great tool to optimize subwoofer and loudspeaker performance based on location and enclosure type.

JBL Stage Amplifier A6002 Cool industrial design - Image

Cool industrial design

Black with deep grooves, silver silkscreen, anodized JBL badge top-center with orange end panels and bottom.

JBL Stage Amplifier A6002 Crossover mode switch - Image

Crossover mode switch

LPF crossover controls is switchable between 0dB to 12dB at 45 Hz giving user ability to adjust sound to the environment and/or application.

JBL Stage Amplifier A6002 Crossover control gives user additional fine tuning - Image

Crossover control gives user additional fine tuning

Adjusts the crossover turnover frequency between 32Hz and 320Hz. (One knob for each stereo pair.)

JBL Stage Amplifier A6002 Our Point of View - Image

Our Point of View

JBL believes that life is defined by what you experience. Music helps people have experiences that are more extraordinary, by fully immersing them in each moment. To help people have rich experiences, JBL creates full-on sound that draws people in and heightens the feeling. JBL is dedicated to delivering sound that elevates life.

Specs & Downloads

Item# STAGEA6002AM

Description

POWER YOU WILL FEEL AT YOUR CORE

JBL Stage Amps are available in a variety of configurations, delivering the right power and number of channels for full-range and subwoofer applications. For more than four decades, JBL has made the audio experience a lot more satisfying for the car audio enthusiast. With a broad array of loudspeakers, amplifiers and subwooers available, you can drive with ease and exhilaration. These compact amps are equipped with all the important inputs and user controls including a bass EQ as well as LPF and HPF crossover controls for tailoring sound to suit the characteristics of different vehicles. The Stage Amps are easily installed and amazingly reliable—and once they turn on, they'll make a transducer sit up and sing.

General Specifications

Power Output
60Wx2@4ohms
Frequency Response
20-20kHz±1dB
THD@ROP
1%
Input Sensitivity
0.2V-5V
High Pass Filter, Variable
32-320Hz
Low Pass Filter, Variable
32-320Hz
Bass EQ@45Hz
0-12dB
Protection
DC, OVP, UVP, OCP, OTP

What's in The Box?

  • 1 x Amplifier
  • 1 x Spare Fuse (x2 for 1-channel and 4-channel model)
  • 1 x High-level input cable (x2 for 4-channel model)
  • 2 x Two-color JBL brand stickers
  • 1 x Quick start guide
What's in The Box?

Documents & Downloads

Reviews and Q&A

Customer Reviews

  • bvseo_sdk, dw_cartridge, 18.2.0, p_sdk_3.2.0
  • CLOUD, getReviews, 4ms
  • reviews, product
  • bvseo-msg: Unsuccessful GET. status = 'ERROR', msg = 'Not Found.'; Unsuccessful GET. status = 'ERROR', msg = 'Not Found.';

Product Q&A

I’m looking into buying 2 JBL Stage 1200B Subwoofer could this amp work well with it? And if not which one do you recommend

Asked by: Miguel13
The JBL Stage 6002 is a car speaker amplifier. What you will need is a subwoofer amplifier. like the JBL CLUB 5501. This model is recommended for 2 of your  JBL Stage 1200B subwoofers.
Answered by: Paulo C
Date published: 2021-10-12

i purchased the JBL cinema 510 & i need an amplifier . which is the most affordable amplifier i can purchase ?

Asked by: Kaycee
We would like to get more information to help you out, please submit a case request and so we can assist you: www.jbl.com/support-contact.html
Answered by: Mario at Customer service
Date published: 2021-06-06

Is it a class AB or class D

Asked by: Jeffrey777
Our JBL Stage A6002 is a Class D Car Audio Amplifier.
Answered by: Customer Support
Date published: 2021-11-27

Hi i am getting 2 JBL Stage 1210 Subwoofer will this be a good amp if not what will be?

Asked by: Kevin101
We would like to work with you directly to help you with your issue. Please submit a case request at https://www.jbl.com/support-contact.html and the Customer Service Team will be more than happy to assist you.
Answered by: Mario at Customer service
Date published: 2021-06-06

Is this a class d amp

Asked by: Duece
Yes, it is a Class D amp.
Answered by: Steven M
Date published: 2021-06-06

Does this have auto turn on and off so I don't need remote power line?

Asked by: Brandon68189
Our JBL Stage Amplifier A6002 has to be connected using a 20-gauge wire from the “Remote Out” lead of the source unit to the REM input. This lead turns the amplifier on when using low-level input signals. If your stereo has no “Remote Out” lead, connect the amplifier’s REM input to switched accessory power.
Answered by: Chastine
Date published: 2021-06-06

I’m looking to power just one single center front midrange speaker. When crossed at 250hz, the midrange is rated at 100W peak. Is this A6002 amp suitable?

Asked by: Peter35
We would like to work with you directly to help you with your issue. Please submit a case request at https://www.jbl.com/support-contact.html and the Customer Service Team will be more than happy to assist you.
Answered by: Mario at Customer service
Date published: 2021-06-06

Can I use a JBL Stage Amplifier A3001 with the JBL CS1214T 30cm 4 ohms subwoofer?

Asked by: Horace
Yes, our Stage Amplifier A6002 will be able to power the JBL CS1214T as the subwoofer can take a peak load of 1000 Watts.
Answered by: Customer Support
Date published: 2022-08-15
