XLS 1502
$535.00
5.0 (1)
Write a review

Features

XLS 1502 Weighs less than 11 lb (5 kg) - Image

Weighs less than 11 lb (5 kg)

Class D amp with Crown's ultra-efficient DriveCore technology weighs less than 11 lb (5 kg)

XLS 1502 Increased lighting functionality - Image

Increased lighting functionality

Turn off all LED indicators except clip and thermal to reduce distraction in dark venues

XLS 1502 Peakx™ Limiters - Image

Peakx™ Limiters

Provide maximum output while protecting your speakers

XLS 1502 Efficient forced-air fans - Image

Efficient forced-air fans

Prevent excessive thermal buildup

Specs & Downloads

Item# NXLS1502-0-US

Description

Meet the new XLS DriveCore 2 Series

The next generation of XLS got a makeover with a sleek new look, a LCD display that is three times larger, and more DSP with higher capabilities. Like its predecessor, the new XLS is ultra-efficient with Crown’s patented DriveCore technology and can drive 2400W at 4Ω bridged with tons of headroom guaranteeing a clean, undistorted signal straight to your speakers. The XLS DriveCore 2 assures that you will be heard as you deliver a powerful, pure sound experience for any venue.

General Specifications

Rated Power Output (W, stereo, per channel at 4Ω)
525
Sensitivity (V, for full rated power at 4Ω)
0.775 / 1.4
Signal to Noise Ratio (dB, below rated 1kHz power at 8Ω, A-weighted)
>103
Total Harmonic Distortion (THD)
< 0.5%
Input Impedance (K Ohms, balanced)
20
Input Impedance (K Ohms, unbalanced)
10

Dimensions

Height (in)
3.5
Depth (in)
7.7
Width (in)
19.0
Weight (lbs)
8.6
Height (mm)
89.0
Width (mm)
482.6
Depth (mm)
196
Weight (kg)
3.9

Features

Peakx™ limiters
Yes
Forced-air cooling
Yes
XLR inputs
Yes
RCA inputs
Yes
1/4" inputs
Yes
User selectable input sensitivity
Yes
Speakon® and binding post outputs
Yes
LCD display
Yes
Remote power trigger
Yes
PureBand™ Crossover System
Yes

Documents & Downloads

Reviews and Q&A

Customer Reviews

  • bvseo_sdk, dw_cartridge, 18.2.0, p_sdk_3.2.0
  • CLOUD, getReviews, 6ms
  • reviews, product
  • bvseo-msg: Unsuccessful GET. status = 'ERROR', msg = 'Not Found.'; Unsuccessful GET. status = 'ERROR', msg = 'Not Found.';

Product Q&A

Can you please post info/specs regarding this amp's DSP capabilities?

Asked by: SND300
We would like to get more information to help you out, please contact us so we can assist you: https://bit.ly/36q7t27
Answered by: Mario at Customer Service
Date published: 2021-06-06

What&rsquo;s voltage gain in dB of XLS 1502 Class D power amplifier &hellip; when sensitivity is .775 Vrms?

Asked by: Lungo
Thanks for reaching out. We want you to get the most out of our product. It would be best if we can work with you directly to get more information and provide the best setup for your XLS 1502. Please Contact JBL Customer Service for technical support and assistance.
Answered by: Customer Support
Date published: 2022-03-27
